Features

• 20 parameters+3 histograms
• 3-part differentiation of WBC
• 2 Counting mode: whole blood and prediluted
• Throughput: Up to 60 samples per hour
• Built-in thermal printer
• External AC adapter avoids electronic noises, enhancing accuracy
• Up to 30000 sample results(including histograms) can be stored
• Multi-language software available on request

Technical Specifications

• Parameters: WBC, LYM#, MID#, GRA#, LYM%, MID%,
  GRA%, RBC, HGB, MCHC , MCH, MCV, RDW-CV,
  RDW-SD, HCT, PLT, MPV, PDW, PCT, P-LCR
  and Histograms for WBC, RBC and PLT
• Principle: Electrical resistance for counfing WBC, RBC and PLT
• Sample Volume: Prediluted:20uL; Whole Blood:9.8uL
• Throughput: 60 samples per hour
• Display: 4″ TFT color LCD with touch screen
• Alarms: Error messages
• Input/Output: RS-232, USB, LAN, keyboard and mouse interface
• Printout: Thermal printer, 55mm width paper, various
  printout formats, external printer optional
• Operating Environment: Temperature : 15℃- 35℃ : Humidity: ≤80%
• Power Requirement: 110V-220V, 50/60Hz
• Dimension: L×W×H（mm）：436 x 363 x 367
• Weight: 18Kg
